China MG14H FEED THROUGH TERMINAL BLOCK Factory
+86-0574-63519570/+86-0574-63519552
China MG14H FEED THROUGH TERMINAL BLOCK Factory
| 认证 |  |
APPROVAL | |
||
| 材质及电镀 | MATERIAL | ||||
| 间距 | 13.5 MM | Pitch | 13.5 MM | ||
| 极数 | 2-12P | Poles | 2-12P | ||
| 螺丝 | M4、钢、镀锌 | Screws | M4、Steel、Zinc plated | ||
| 端子 | 合金、镀镍 | Contact | Alloy、Ni Plated | ||
| 簧片 | 不锈钢 | Clips | Stainless steel | ||
| 塑件 | PA66.UL94V-0 | Housing | PA66.UL94V-0 | ||
| 电气性能 | UL | IEC | ELECTRICAL | UL | IEC |
| 额定电压 | 300V | 750V | Rated voltage | 300V | 750V |
| 额定电流 | 50A | 57A | Rated current | 50A | 57A |
| 耐电压 | AC3000V/1Min | Withstanding Voltage | AC3000V/1Min | ||
| 使用线径 | 12-8AWG | Wire range | 12-8AWG | ||
| 机械性能 | MECHANICAL | ||||
| 温度范围 | -40℃～+105℃ | Temp.Range | -40℃～+105℃ | ||
| 扭矩 | 1.2Nm(10.5lb.in.) | Torque | 1.2Nm(10.5lb.in.) | ||
