PCB SCREW TERMINAL BLOCK

MG129-7.5/7.62 PCB SCREW TERMINAL BLOCK Wholesale

MG129-7.5/7.62
PCB SCREW TERMINAL BLOCK

认证		APPROVAL

材质及电镀		MATERIAL
间距	7.5/7.62MM	Pitch	7.5/7.62MM
极数	2P、3P	Poles	2P、3P
螺丝	M3、钢、镀锌	Screws	M3、Steel、Zinc Plated
方扣	钢、镀锌或黄铜、镀镍	Wire cage	Steel、Zinc plaed or Brass、Ni plated
焊针	黄铜、镀锡	Pin Header	Brass、Tin Plated
塑件	PA66.UL94V-0	Housing	PA66.UL94V-0

电气性能		ELECTRICAL
额定电压	300V	Rated voltage	300V
额定电流	25A	Rated current	25A
耐电压	AC2000V/1Min	Withstanding Voltage	AC2000V/1Min
使用线径	26-12AWG	Wire range	26-12AWG

机械性能		MECHANICAL
温度范围	-40℃～+105℃	Temp.Range	-40℃～+105℃
瞬时温度	+250℃5秒	MAX soldering	+250℃ for 5 sec.
扭矩	0.5Nm（4.4lb.in)	Torque	0.5Nm（4.4lb.in)
剥线长度	6-7mm	Strip length	6-7mm
