PCB SCREW TERMINAL BLOCK

MG500HH-5.0/5.08 PCB SCREW TERMINAL BLOCK Wholesale

MG500HH-5.0/5.08
PCB SCREW TERMINAL BLOCK

认证		APPROVAL

材质及电镀		MATERIAL
间距	5.0/5.08MM	Pitch	5.0/5.08MM
极数	2P、3P	Poles	2P、3P
螺丝	M2.5、钢、镀锌	Screws	M2.5、Steel、Zinc Plated
方扣	钢、镀锌或黄铜、镀镍	Wire cage	Steel、Zinc plaed or Brass、Ni plated
焊针	黄铜、镀锡	Pin Header	Brass、Tin Plated
塑件	PA66.UL94V-0	Housing	PA66.UL94V-0

电气性能		ELECTRICAL
额定电压	300V	Rated voltage	300V
额定电流	10A	Rated current	10A
耐电压	AC2000V/1Min	Withstanding Voltage	AC2000V/1Min
使用线径	24-12AWG	Wire range	24-12AWG

机械性能		MECHANICAL
温度范围	-40℃～+105℃	Temp.Range	-40℃～+105℃
瞬时温度	+250℃5秒	MAX soldering	+250℃ for 5 sec.
扭矩	0.4Nm（3.5lb.in)	Torque	0.4Nm（3.5lb.in)
剥线长度	6-7mm	Strip length	6-7mm
