China MG9034 PCB SCREW TERMINAL BLOCK Factory
+86-0574-63519570/+86-0574-63519552
China MG9034 PCB SCREW TERMINAL BLOCK Factory
| 材质及电镀 | MATERIAL | ||
| 间距 | 3.5MM | Pitch | 3.5MM |
| 极数 | 4P | Poles | 4P |
| 螺丝 | M2、钢、镀镍 | Screws | M2、Steel、Ni Plated |
| 弹片 | 不锈钢 | Clips | Stainless steel |
| 焊针 | 黄铜、镀锡 | Pin Header | Brass、Tin Plated |
| 塑件 | PA66.UL94V-0 | Housing | PA66.UL94V-0 |
| 电气性能 | ELECTRICAL | ||
| 额定电压 | 125V | Rated voltage | 125V |
| 额定电流 | 10A | Rated current | 10A |
| 耐电压 | AC2000V/1Min | Withstanding Voltage | AC2000V/1Min |
| 使用线径 | 26-16AWG | Wire range | 26-16AWG |
| 机械性能 | MECHANICAL | ||
| 温度范围 | -33℃～+120℃ | Temp.Range | -33℃～+120℃ |
| 瞬时温度 | +250℃5秒 | MAX soldering | +250℃ for 5 sec. |
| 剥线长度 | 5-6mm | Strip length | 5-6mm |
