China MG390-5.0 PCB SPRING TERMINAL BLOCK Factory
+86-0574-63519570/+86-0574-63519552
China MG390-5.0 PCB SPRING TERMINAL BLOCK Factory
| 材质及电镀 | MATERIAL | ||
| 间距 | 5.0MM | Pitch | 5.0MM |
| 极数 | 1P-XXP | Poles | 1P-XXP |
| 焊针 | 黄铜、镀锡 | Contact | Brass、Tin Plated |
| 弹片 | 不锈钢 | Clips | Stainless steel |
| 塑件 | PA66.UL94V-0 | Housing | PA66.UL94V-0 |
| 电气性能 | ELECTRICAL | ||
| 额定电压 | 300V | Rated voltage | 300V |
| 额定电流 | 8A | Rated current | 8A |
| 耐电压 | AC2000V/1Min | Withstanding Voltage | AC2000V/1Min |
| 使用线径 | 22-18AWG | Wire range | 22-18AWG |
| 机械性能 | MECHANICAL | ||
| 温度范围 | -33℃～+120℃ | Temp.Range | -33℃～+120℃ |
| 瞬时温度 | +250℃5秒 | MAX soldering | +250℃ for 5 sec. |
| 剥线长度 | 9-10mm | Strip length | 9-10mm |
