15EMGKDM-3.5/3.81 PLUG-IN TERMINAL BLOCK

15EMGKDM-3.5/3.81
PLUG-IN TERMINAL BLOCK

0
Views: 2,105
Contact us

Product parameters

 材质及电镀  MATERIAL
 间距 3.5/3.81MM  Pitch 3.5/3.81MM
 极数 2P-24P  Poles 2P-24P
弹片 不锈钢 Clips Stainless steel
触点材料 磷青铜、镀锡 Wire guard Phosphor bronza、Tin Plated
 塑件  PA66.UL94V0  Housing  PA66.UL94V0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage 300V
 额定电流  8A  Rated current 8A
 耐电压  AC2000V/1Min  Withstanding Voltage   AC2000V/1Min
 使用线径 28-16AWG  Wire range 28-16AWG

 机械性能    MECHANICAL
 温度范围  -40℃～+105℃  Temp.Range  -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
 剥线长度 9mm  Strip length 9mm
