PLUG-IN TERMINAL BLOCK

15EMGR-2.5 PLUG-IN TERMINAL BLOCK Wholesale

15EMGR-2.5 PLUG-IN TERMINAL BLOCK

15EMGR-2.5
PLUG-IN TERMINAL BLOCK

0
Views: 1,251
Contact us

Product parameters

 材质及电镀  MATERIAL
 间距 2.5MM  Pitch 2.5MM
 极数 2P-12P  Poles 2P-12P
 焊针 黄铜、镀锡  Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  125V  Rated voltage  125V
 额定电流 4A  Rated current 4A
 耐电压  AC1250V/1Min  Withstanding Voltage   AC1250V/1Min

 机械性能    MECHANICAL
 温度范围  -40℃～+105℃  Temp.Range  -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.



DRAWING DOWNLOAD
