PLUG-IN TERMINAL BLOCK

15EMGVC-3.5/3.81 PLUG-IN TERMINAL BLOCK Wholesale

15EMGVC-3.5/3.81 PLUG-IN TERMINAL BLOCK

15EMGVC-3.5/3.81
PLUG-IN TERMINAL BLOCK

0
Views: 1,041
Contact us

Product parameters

 认证  APPROVAL

 材质及电镀  MATERIAL
 间距 3.5/3.81MM  Pitch 3.5/3.81MM
 极数 2P-24P  Poles 2P-24P
 焊针 黄铜、镀锡  Pin Header Brass、Tin Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流 8A  Rated current 8A
 耐电压  AC2000V/1Min  Withstanding Voltage   AC2000V/1Min

 机械性能    MECHANICAL
 温度范围 -40℃～+105℃  Temp.Range -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.



DRAWING DOWNLOAD

15EMGVC-3.5 15EMGVC-3.81
