PLUG-IN TERMINAL BLOCK

2EMGRH-5.0/5.08 PLUG-IN TERMINAL BLOCK Wholesale

2EMGRH-5.0/5.08 PLUG-IN TERMINAL BLOCK

2EMGRH-5.0/5.08
PLUG-IN TERMINAL BLOCK

0
Views: 2,089
Contact us

Product parameters

 认证  APPROVAL

 材质及电镀  MATERIAL
 间距 5.0/5.08MM  Pitch 5.0/5.08MM
 极数 2P-24P  Poles 2P-24P
 焊针 黄铜、镀镍  Pin Header Brass、Ni Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流  15A  Rated current  15A
 耐电压  AC2500V/1Min  Withstanding Voltage   AC2500V/1Min

 机械性能    MECHANICAL
 温度范围  -40℃～+105℃  Temp.Range  -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.



DRAWING DOWNLOAD

2EMGRH-5.08
