Home / Product / PLUG-IN TERMINAL BLOCK / 2EMGUVK-5.08
PLUG-IN TERMINAL BLOCK

2EMGUVK-5.08 PLUG-IN TERMINAL BLOCK Wholesale

2EMGUVK-5.08 PLUG-IN TERMINAL BLOCK

2EMGUVK-5.08
PLUG-IN TERMINAL BLOCK

0
Views: 797
Contact us

Product parameters

 认证  APPROVAL

 材质及电镀  MATERIAL
 间距 5.08MM  Pitch 5.08MM
 极数 2P-24P  Poles 2P-24P
螺丝 M2.5、钢、镀锌 Screws M2.5、Steel、Zinc Plated
触点材料 黄铜、镀锡 Wire guard Brass、Tin Plated
方扣 黄铜、镀镍 Contact Brass、Ni Plated
 塑件  PA66.UL94V-0  Housing  PA66.UL94V-0

 电气性能    ELECTRICAL
 额定电压  300V  Rated voltage  300V
 额定电流 10A  Rated current 10A
 耐电压  AC2500V/1Min  Withstanding Voltage   AC2500V/1Min
使用线径 28-12AWG Wire range 28-12AWG

 机械性能    MECHANICAL
 温度范围  -40℃～+105℃  Temp.Range  -40℃～+105℃
 瞬时温度  +250℃5秒  MAX soldering  +250℃ for 5 sec.
扭矩 0.4Nm（3.5b.in) Torque 0.4Nm（3.5b.in)
剥线长度 7mm Strip length 7mm



DRAWING DOWNLOAD

2EMGUVK-5.08
